- Brand Name: Earykong
- Zone Number: 4 wired defense + 100 wireless defense
- Kit Configuration: Door/Window Sensor
- Alarm Type: SMS,PSTN,Apps Control,The Alarm
- Communication Interface: Wireless
- Power: DC 12V
- Model Number: M3B
- Output Number: Relay output + 4 wired defense
- Arming Type: FR Remote-controller
- Video Interface: Yes
- Display: Yes
- Password Keyboard: Yes
- Voice Prompt Language: English/Russian/Spanish/French
- Manual: English/Russian/Spanish/French Manual
- Wireless Transmission Freqency: 433MHz
- Warranty: 2 Years
- GSM Frequency: 850/900/1800/1900MHz
- zone: 99 wireless zone and 4 wired zone
- Voltage: 110-240V US/EU/AU/UK (Optional)
- Relay output: yes, (5A 250V),(7A 125V),(20A 14V)
Wireless Home PSTN GSM Telephone Auto-dial Security Burglar Alarm System
1. This alarm system is 433MHz GSM + PSTN alarm system.
2. We can provide you many options
Choose ‘A’: English Manual + English Voice Prompt (As default)
Choose ‘B’: Russian Manual + Russian Voice Prompt
Choose ‘C’: Spanish Manual + Spanish Voice Prompt
Choose ‘D’: French Manual + French Voice Prompt
3. If you want to get more detail information, please send your email to me, and I will send the “PDF Manual” to your email in 10 hours. you can translate to your language by google translate,
4. All kinds of wireless detector in my store will compatible with the alarm system, and you can add 100 pieces of wireless detector at most.
If you need more accessories,See the following link for more details…
This is new Upgrade system, Support the cell phone remote control home device.
Support telephone line and GSM SIM card.
Adopt high speed technology, smart control alarm system.
Support 4 set of smart timing Arm and Disarm…
When system alarm, you can get alarm phone call and alarm message.
Support Phone APP.
Smart analyze wireless detector. you can 8 kinds of alarm mode.
1. Normal detector.
2. Stay Arm
8. Help Sensor
- Large LCD English blue back-light display, voice prompt, ease of use.
- Support dual-network of both PSTN landline and GSM mobile network, provide redundancy for extra stability.
- Can check status and call records from panel.
- Allow up to 99 wireless defense zones and 4 wired zones.
- Each can be defined as one of the 8 zone types including NORMAL, STAY, INTELLIGENT, EMERGENCY, CLOSED, HELP SENIOR, WELCOME and CHIME.
- Four sets of scheduled arm/disarmed function, each time disarmed you can select the included period of time and different defense zone, eliminating of need of the manual procedure, realizing the beauty of automatic controls.
- Support configuration via phone ( handset ) or SMS messages to System Setup text messaging costs associated with the alarm panel.
- 6 group voice alarm phone number for alert calling, 3 group phone number for help senior, 6 group for SMS messaging, numbers saved inside EEPROM without lost upon power failure.
- Different zones can dial a pre-set telephone number.
- Support ISD automatic voice mailbox for playback message upon alert. Maximum length of voice message is 10 seconds.
- Telephone (phone) long-distance telephone control for arming, disarming, monitoring, remote announcement.
- 1 Set of normally open signal outputs, relay linkage output, home appliances remote control can be realized.
- Wireless intelligent study coding, compatible with PT2262 normal encoding and a 1527 encoding, convenient and flexible for adding or reducing accessories. Maximum support 150 remote control and 150 sensors.
- Unique black box features, you can display most recent 72 disarmed records and 102 recent alarm recording. Accurately shows the alarm time and control code.
- Built-in Ni-Hi rechargeable battery and automatically switchable upon power failure, and notification will be sent via SMS.
- Panel integrated with either dual-band, triple-band, quad-band GSM/GPRS industrial graded module, stable and reliable.
This LCD English large-screen GSM alarm system is equipped with dual network technologies and suitable for both home and commercial use. It uses the advanced GSM digital signal process technology, GSM Wireless mobile and traditional PSTN landline networks with intelligent alarm system. It has highly integrated digital voice, SMS, self-learning wireless communication code, remote appliance control and text messaging technologies. The alarm provides automatic voice or SMS message as notifications for incidents. It is a choice of stability, reliability, security, and user friendliness. Features are very practical, cost-effective, completed configuration and ease of use. This large LCD display alarm can integrate with a lot of alarm accessories including door sensor, smoke detectors, gas detectors, emergency buttons and other accessories to build a powerful security setup. It has been widely used in homes, factories, schools, shops, convenience stores, financial and banking workplace, community centre and residential area to provide protection to valuable assets.
Product Usage Step:
After you get your parcel, you can use this alarm system by below steps..
1. Insert a SIM card ,or connect the telephone line, connect the wired siren, connect the power adapter
2. Configure the remote controller or the wireless detector, (before we send it, we have already configure all the wireless accessories)
3. Set up the alarm call phone number, +[1-9]+[phone number]+[#], you can set 1-9, 9 set of phone number.
4. Set up the alarm SMS phone number, +[1-6]+[phone number]+[#], you can set 1-6, 6 set of phone number.
5. Set the password, +[4 digits new password]+[#], for example , input cmd : 504321#
6. Adjust the siren volume,+[00-99]+[#], system default is the largest volume.
Note: Due to the airlines limit, some battery is not included in the package;
1 * GSM & PSTN Dual-Network Burglar Alarm System (include the battery)
2 * Wireless Remote Controller (include the battery )
2 * Wireless Door / Window Sensor (Battery not include)
2 * Wireless Infrared Sensor (Battery not include)
1 * DC 12V Power Adaptor
1 * User Manual
1 * Wired Siren
Warm Prompt: 1. If you want Russian / Spanish / French language, please tell me after you order it..Or I will send English language
2. This Alarm system can connect with 100 wireless remote controller and 100 wireless detector,you can add by yourself
3. If you are interested in this alarm system, please send your email to me, and I will send the manual to your email, I think it will help you, thank you!!
